Rexroth Indramat ECODRIVE03 Series User Manual

4-42 ECODRIVE03 DKC**.040, DKC**.100, DKC**.200 ECODRIVE03 Drive Controllers
Connections on top of the drive controller
Fa5025f1.fh7
XS3:
cable clamp
bracket
shield connection
DKC**.3-100-7-FW
X11:
interface for
ZKS control
DKC**.3-040-7-FW
XS3
X9:
incremental encoder/
SSI-emulation
X10:
expansion
interface
XS3
Fig. 4-45: Connections on top of unit for DKC**.3-040-7-FW and
DKC**.3-100-7-FW
