Controller data Controller SP5-801-xxx
SCS, IMH, MCS, Copier application,
Fax application, Printer application,
Scanner application, Web service/
network application, NCS, R-Fax,
DCS, UCS
Exceptions
SP5-998-001 clears most of the settings and counters stored in the NVRAM on the BICU (the values return
to their default values). However, the following settings are not cleared:
• SP5-807 (Area Selection)
• SP5-811-001 (Serial Num Input [Code Set])
• SP5-811-003 (Serial Num Input [ID2 Code Display])
• SP5-812-001 (Service TEL [Telephone])
• SP5-812-002 (Service TEL [Facsimile])
• SP5-907 (Plug & Play)
• SP7 (Data Log)
• SP8 (History)
Use SP5-998-001 after you have replaced the BICU NVRAM or when the BICU NVRAM data is corrupted.
When the program ends normally, the message "Completed" is displayed. When you have replaced the
controller NVRAM or when the controller NVRAM data is corrupted, use SP5-801-001. The message is
the same as the basic machine.
Memory Clear Procedure
1. Print out all SMC data lists (* "SMC Print").
2. Do SP5-998-001.
3. Press the OK key.
4. Select "Execute." The messages "Execute?" followed by "Cancel" and "Execute" are displayed.
5. Select "Execute."
6. When the program has ended normally, the message "Completed" is displayed. If the program has
ended abnormally, an error message is displayed.
7. Turn the main switch off and on.
8. Adjust the printer and scanner registration and magnification (* "Copy Adjustment" in the chapter
"Replacement and Adjustment").
9. Refer to the SMC lists, and enter any values that differ from the factory settings. Double-check the
values for SP4-901.
Service Program
219
