5. When having installed a new PCU, remove the Styrofoam and tags (* "Installation Procedure" in the
chapter "Installation").
Initialization
After you turn on the main power switch, the copier automatically initializes the new PCU. When the copier
is executing initialization, it is important that you:
Do not turn off the main power switch.
Do not open or remove exterior covers.
Quenching Lamp
1. PCU (* "PCU")
2. Quenching lamp [A] ( x 1)
PCU and Quenching Lamp
65
3
