6. Print out the configuration page (User Tools/Counter > Printer Features > List/Test Print), and then
check that this device is detected.
If reception is poor, you may need to move the machine:
• Make sure that the machine is not located near an appliance or any type of equipment that could
generate a strong magnetic field.
• Position the machine as close as possible to the access point.
SP Mode Settings for IEEE 802.11b Wireless LAN
The following SP commands can be set for IEEE 802.11b
SP No. Name Function
5840 004 SSID Used to confirm the current SSID setting.
5840 006 Channel MAX Sets the maximum range of the channel settings for the country.
5840 007 Channel MIN
Sets the minimum range of the channel settings allowed for your
country.
5840 011 WEP Key Select Used to select the WEP key (Default: 00).
5840 018 SSID Check Used to check the SSID.
5840 020 WEP Mode
Used to display the maximum length of the string that can be
used for the WEP Key entry.
IEEE 1284 Installation
• Unplug the machine power cord before starting the following procedure.
Component Check
No. Description Q’ty
1 IEEE1284 Interface Ass’y 1
2 UL Sheet 1
3 Caution Sheet 1
1. Installation
38
