Development
Overview
The development section consists of the following parts.
1. Development Roller
2. ID Sensor
3. Mixing Auger 2
4. TD Sensor
5. Mixing Auger 1
6. Doctor Blade
The two mixing augers mix the developer (carrier/toner mix). The TD (toner density) sensor and the ID
(image density) sensor are used to control the copy image density.
6. Detailed Section Descriptions
266
6
