2. Original feed unit [A] ( x 1)
Separation Roller
1. Open the DF left cover.
2. Original feed unit (* "Original Feed Unit")
3. Separation roller cover [A] (hook x 2)
4. Separation roller stopper [B] (hook)
5. Separation roller [C]
DF Drive Board
1. DF rear cover (* "DF Rear Cover")
ARDF
93
3
