Ricoh S-C3 F - Right Door

2. Rear cover (* "Rear Cover")
3. Slide the upper left cover [A] to the rear.
4. Rear scale [B] ( x 3)
5. Slide the upper right cover [C] to the rear.
6. Front left cover [D] ( x 2)
7. Operation panel [E] (x 4,  x 1)
8. Front right cover [F]
Right Door
1. Open the right door [A].
2. Release the strap [B].
3. Right door ( × 1)
Exterior Covers and Operation Panel
