*1
: The PCI is available to the models with the controller box.
*2:
The original image on the exposure glass is printed behind the test pattern.
SMC Print (SP5-990)
SP5-990 outputs machine status lists.
1. Select SP5-990.
2. Select a menu:
• GW machine: 001 All (Data List), 002 SP (Mode Data List), 003 User Program, 004 Logging
Data, 005 Diagnostic Report, 006 Non-Default, 007 NIB Summary, 008 Net File Log, 021
Copier User Program, 022 Scanner SP, 023 Scanner User Program, 040 Parts Alarm Counter
Print, 064 Normal Count Print, 065 User Code Counter, 066 Key Operator Counter, 067
Contact List Print, 069 Heading1 print, 071 Heading3 print, 072 Group List Print, 128 ACC
Pattern, 129 User Color Pattern, or 160:ACC Pattern Scan
• The output given by the menu "Big Font" is suitable for faxing.
3. Press the "Execute" key.
• GW machine: The machine status list is output.
4. To return to the SP mode, press the key.
Power-on Self Test
The controller tests the following devices at power-on. If an error is detected, an error code is stored in the
controller board.
• CPU, ASIC and clock
• Flash ROM
• Resident and optional SDRAM
• NVRAM
PS fonts (if installed)
Service Program
233
