Ricoh S-C3 F - Exit Sensor; Hot Roller Stripper Pawls

Exit Sensor
1. Fusing unit (* "Fusing Unit")
2. Exit sensor [A] ( × 1)
Hot Roller Stripper Pawls
• Take care not to damage the hot roller stripper pawls and the tension springs.
3. Replacement and Adjustment
58
3
