Paper Tray Unit
Accessory Check
Confirm that you have these accessories.
Description Q’ty
1. Paper-size decals 1 sheet
2. Installation Procedure (for service person) 1
3. Installation Procedure (for user) 1
Installation Procedure
Unplug the main machine's power cord before starting the following procedure.
1. Remove the tape at [A], and the tape and cardboard at [B].
2. Pull the paper tray part way out of the unit, remove the tape and cardboard at [C], and push the tray
back in.
Paper Tray Unit
25
1
