Exterior Covers and Operation Panel
Rear Cover
1. Open the right door [A].
2. Rear cover [B] ( x 5)
Copy Tray
Make sure that the cables under the copy tray are in place before reassembling the copier. If these
cables are caught between the copy tray and the inner cover, they may be severely damaged.
Exterior Covers and Operation Panel
47
3
