Thermoswitches and Thermistor
1. Hot roller assembly (* "Hot Roller & Fusing Lamp")
2. Thermoswitches ( x 2 for each)
3. Thermistor ( x 1)
Reassembling
Make sure of the following:
• That the thermistor is in contact with the hot roller.
• That the hot roller turns smoothly.
• Do not recycle a thermoswitch that is already opened. Safety is not guaranteed if you do this.
Fusing
61
