Ricoh S-C3 F - Overview

6. Detailed Section Descriptions
Overview
Component Layout
Mainframe
1. Exposure Lamp
2. 1st Scanner
3. CCD (on SBU)
4. Lens Block
5. 2nd Scanner
6. 2nd Mirror
7. 3rd Mirror
20. ID (Image Density) Sensor
21. Registration Roller
22. Registration Sensor
23. Bypass Tray
24. Bypass Paper Feed Roller
25. Bypass Paper End Sensor
26. Bypass Friction Pad
237
6
