Paper Feed
Overview
1. Exit Roller
2. Exit Sensor
3. Registration Sensor
4. Bypass Feed Roller
5. Bypass Paper End Sensor
6. Bypass Friction Pad
7. (Main) Friction Pad
8. (Main) Paper End Sensor
9. Paper Feed Roller
10. Registration Roller
