Ricoh S-C3 F - IEEE 1284 Installation

Component Check
No. Description Q’ty
1 Wireless Adapter 1
2 Wireless LAN Card 1
3 LAN Card Cover 4
4 Caution Sheet 1
5 Label 1
Installation Procedure
1. Remove the interface cover [A] ( x 2).
2. Install the Wireless adaptor into the slot A [B] ( x 2).
3. Install the Wireless LAN card in the wireless adaptor.
4. Attach the antenna cap to the wireless LAN card.
5. Turn on the main power switch.
Controller Options
