Installation Procedure
1. Attach the handset bracket [A] ( x 2).
• The bracket is an accessory of the copier.
2. Remove the label [B] from the handset cradle [C].
3. Attach the cradle to the bracket ( x 2).
4. Reattach the label.
5. Set the handset [D] on the cradle.
