ARDF
1. DF Feed Clutch
2. Registration Sensor
3. Exit Sensor
4. Left Cover Sensor
5. DF Transport Motor
6. DF Feed Motor
7. Inverter Sensor
8. DF Drive Board
9. Junction Gate Solenoid
10. Original Set Sensor
Overview
241
6
