Ready 150°C SP1-105-003
Copying 160°C SP1-105-005
Low level 60°C SP1-105-007
Thick paper 165°C SP1-105-009
Temperature Transition
When the fusing unit is cool, the fusing temperature should be higher to ameliorate the fusing quality. During
copying, the fusing temperature is controlled in four phases as listed in the table. “Default” is the target
fusing temperature of SP1-105-005 (160°C). “Example” is the target fusing temperature of the case where
you specify “165°C” in SP1-105-005.
Start key pushed
(À)
For one
second (Á)
30 seconds
later (Â)
60 seconds
later (Ã)
Default 175°C 170°C 165°C 160°C
Example 180°C 175°C 170°C 165°C
Difference from
SP1-105-005
+15°C +10°C +5°C —
Copy SP1-105-005 adjusts the fusing temperature of the fourth phase (Ã). You cannot directly adjust the
fusing temperature in the first three phases (À through Â). They are always higher than the fourth phase
(Ã) by 15°C, 10°C, and 5°C respectively.
Image Fusing and Paper Exit
287
