Procedure
1. Open the right door [A].
2. Remove the rear cover [B] ( x 5).
3. Controller box cover [C] ( x 12)
4. FCU [D] ( x 3, x 1)
5. When you replace the FCU board, remove the MBU board from the old FCU board and install it on
the new FCU board.
6. Set the correct date and time with the User Tools: User Tools> System Settings> Timer Setting> Set
Date/Time
• Do not turn off the battery switch (SW1).
• Do SP6-101 in the "Fax SP" to print the system parameters, and check the settings.
3. Replacement and Adjustment
88
