Rigol DP2000 Series Programming Guide

4.13.3 :TRIGger:IN:RESPonse
Syntax
:TRIGger:IN:RESPonse < d >,< res >
:TRIGger:IN:RESPonse? <
d >
Description
Sets or queries the output response of the trigger input for the specified data line.
Parameter
Name Type Range Default
<d> Discrete {D1|D2|D3|D4} D1
<res> Discrete {ON|OFF|ALTER} OFF
Remarks
• OutOn (ON): Turns on the output of the channel currently selected as the source
under control (
:TRIGger:IN[:ENABle] ) when the trigger condition
( :TRIGger:IN:TYPE ) is met.
• OutOff (OFF): Turns off the output of the channel currently selected as the
source under control when the trigger condition (
:TRIGger:IN:TYPE ) is met.
• OutFlip (ALTER): Toggles the channel output state when the trigger condition
( :TRIGger:IN:TYPE ) is met. That is, turns off the channel when the current channel
is on, or turns on the channel when the current channel is off.
Return Format
The query returns ON, OFF, or ALTER.
Examples
:TRIG:IN:RESP D1,ON /*Sets the output response of D1 trigger input
to OutOn.*/
:TRIG:IN:RESP? D1 /*Queries the output response of D1 trigger
input. The query returns ON.*/
4.13.4 :TRIGger:IN:SOURce
Syntax
:TRIGger:IN:SOURce < d >,< ch >
:TRIGger:IN:SOURce? <
d >
Command System
120
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
