Description
Sets or queries the source under control of the trigger input for the specified data
line.
Parameter
Name Type Range Default
<d> Discrete {D1|D2|D3|D4} D1
<ch> ASCII string {CH1[,CH2[,CH3]]} CH1
Remarks
You can select one or more channels from CH1, CH2, and CH3 as the source under
control. If <ch> is omitted, CH1 is selected as the source under control.
Return Format
The query returns the name of the source under control. If the source under control
contains multiple channels, the channels are separated by commas. For example, the
query might return CH1 or CH1,CH2.
Examples
:TRIG:IN:SOUR D1,CH1,CH2 /*Sets the source under control of D1
trigger input to CH1 and CH2.*/
:TRIG:IN:SOUR? D1 /*Queries the source under control of D1 trigger
input. The query returns CH1,CH2.*/
4.13.5 :TRIGger:IN:TYPE
Syntax
:TRIGger:IN:TYPE <
d
>,<
type
>
:TRIGger:IN:TYPE? <
d
>
Description
Sets or queries the trigger type of the trigger input for the specified data line.
Parameter
Name Type Range Default
<d> Discrete {D1|D2|D3|D4} D1
<type> Discrete {RISE|FALL|HIGH|LOW} RISE
Command System
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
121
