4.9.11 [:SOURce[<n>]]:VOLTage:PROTection:STATe
Syntax
[:SOURce[< n >]]:VOLTage:PROTection:STATe < bool >
[:SOURce[<
n >]]:VOLTage:PROTection:STATe?
Description
Sets or queries the on/off state of the overvoltage protection (OVP) function of the
specified channel.
Parameter
Name Type Range Default
<n> Integer {1|2|3} -
<bool> Bool {0|1|ON|OFF} 0
Remarks
• When OVP ( [:SOURce[<n>]]:VOLTage:PROTection:STATe ) is enabled, the output is
disabled automatically if the actual output voltage reaches the OVP level
currently set. You can send
[:SOURce[<n>]]:VOLTage:PROTection:TRIPped? to
query whether an OVP event occurred on the specified channel.
• If [:SOURce[<n>]] or [<n>] is omitted, the command sets the corresponding
parameter of the channel currently selected.
• You can also send
:OUTPut:OVP[:STATe] to enable or disable the OVP function of
the specified channel.
• You can also send
[:SOURce[<n>]]:VOLTage:PROTection[:LEVel] to query the OVP
level of the specified channel.
Return Format
The query returns 1 or 0.
Examples
:VOLT:PROT:STAT ON /*Enables the OVP function for the current
channel.*/
:VOLT:PROT:STAT? /*Queries the on/off state of the OVP function of
the current channel. The query returns 1.*/
4.9.12 [:SOURce[<n>]]:VOLTage:PROTection:TRIPped?
Syntax
[:SOURce[< n >]]:VOLTage:PROTection:TRIPped?
Command System
