Remarks

• When OVP is enabled, the output is disabled automatically if the output voltage

reaches the OVP level currently set. You can send

:OUTPut:OVP:QUES?

:OUTPut:OVP:ALAR?

to query whether an OVP event occurred on the

specified channel.

• If <source> is omitted, the command sets or queries the OVP level of the current

channel.

• You can select “MINimum” to set the minimum OVP level or “MAXimum” to

set the maximum OVP level.

• You can also send

[:SOURce[<n>]]:VOLTage:PROTection[:LEVel]

to set the OVP

level for the specified channel.

Return Format

The query returns the OVP level, for example, 8.800.

Examples

:OUTP:OVP:VAL CH1,8.8 /*Sets the OVP level of CH1 to 8.8 V.*/

:OUTP:OVP:VAL? CH1 /*Queries the OVP level of CH1. The query

returns 8.800.*/

4.8.14 :OUTPut:PAIR

Syntax

:OUTPut:PAIR <

type

:OUTPut:PAIR?

Description

Sets or queries the channel connection mode.

Parameter

Name Type Range Default

<type> Discrete {OFF|PARallel|SERies} OFF

Remarks

• OFF: CH1 and CH2 are independent of each other.

• PARallel: CH1 and CH2 are connected in parallel (internal).

• SERies: CH1 and CH2 are connected in series (internal).

Return Format

The query returns the connection mode, for example, SERIES.

Command System

Rigol DP2000 Series Programming Guide
