Rigol DP2000 Series Programming Guide

Examples
:TRIG:OUT:POLA D1,NEGAtive /*Sets the D1 trigger output signal to
low level.
:TRIG:OUT:POLA? D1 /*Queries the D1 trigger output signal. The
query returns NEGATIVE.*/
4.13.7 :TRIGger:OUT:SOURce
Syntax
:TRIGger:OUT:SOURce < d >,< source >
:TRIGger:OUT:SOURce? <
d >
Description
Sets or queries the control source of the trigger output function of the specified data
line.
Parameter
Name Type Range Default
<d> Discrete {D1|D2|D3|D4} D1
<source> Discrete {CH1|CH2|CH3} CH1
Remarks
You can select any one of CH1, CH2, and CH3 as the control source of trigger output.
Return Format
The query returns the name of the control source selected, for example, CH1.
Examples
:TRIG:OUT:SOUR D1,CH1 /*Sets the control source of D1 trigger
output to CH1.*/
:TRIG:OUT:SOUR? D1 /*Queries the control source of D1 trigger
output. The query returns CH1.*/
4.13.8 :TRIGger:OUT[:ENABle]
Syntax
:TRIGger:OUT[:ENABle] < d >,< bool >
:TRIGger:OUT[:ENABle]? <
d >
Description
Sets or queries the on/off state of the trigger output function for the specified data
line.
Command System
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
123
