:ANALyzer:CURRent:THRE? <

>,<

type

Description

Sets or queries the limit value of positive/negative pulse for the pulse current analysis

function.

Parameter

Name Type Range Default

<ch> Discrete {CH1|CH2} -

<type> Discrete {UP|LOW} -

<bool> Bool {0|1|ON|OFF} OFF

<val> Real 0 to 3.15 A

Positive: 1 A

Negative: 0.1 A

Remarks

• UP sets <val> for positive pulse. In the analysis process, the analyzer records the

number of pulses above the threshold and the most recent pulse width beyond

this upper threshold.

• LOW sets <val> for negative pulse. In the analysis process, the analyzer records

the number of pulses below the threshold and the most recent pulse width

below this threshold.

Return Format

The query returns the on/off state of the upper or lower limit and the specific limit

value for the selected channel. For example, the query may return 1,1.0000.

Examples

:ANALyzer:CURRent:THRE CH1,UP,ON,1 /*Sets the positive pulse

threshold to 1 A for CH1 pulse current analysis.*/

:ANALyzer:CURRent:THRE? CH1,UP /*Queries the positive pulse

threshold for CH1 pulse current analysis. The query returns

1,1.0000.*/

4.1.4 :ANALyzer:SAVE:ROUTe

Syntax

:ANALyzer:SAVE:ROUTe <

dest

:ANALyzer:SAVE:ROUTe?

Command System
