Rigol DP2000 Series Programming Guide

Examples
*SRE 24 /*Enables the bit3 (QUES) and bit4 (MAV) in the enable
register of the Status Byte register and enables the service
request.*/
*SRE? /*Queries the enabled bits in the enable register of the
Status Byte register. The query returns +24.*/
4.3.12 *STB?
Syntax
*STB?
Description
Queries the SUMMARY register of the Status Byte register.
Parameter
None.
Remarks
Executes this command and the query returns a decimal value (corresponding to the
binary-weighted sum of all bits set in the register). This command does not clear the
register. For definitions of the bits in the Status Byte register and the decimal values
corresponding to their binary weights, please refer to
Definitions of the bits in the
Status Byte register and the decimal values corresponding to their binary weights . For
example, if questionable state currently occurs in the instrument and the service
request sent is interrupted, the bit3 (QUES) and bit6 (RQS) in the SUMMARY register
of the Status Byte register are set and the query returns 72 (2
3
+2
6
).
Return Format
The query returns a decimal value, which corresponds to the binary-weighted sum of
all bits set in the SUMMARY register of the Status Byte register. For example, the
query might return +72.
Examples
*STB? /*Queries the SUMMARY register of the Status Byte register.
The query returns +72.*/
4.3.13 *TRG
Syntax
*TRG
Description
Generates an event trigger.
Command System
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
29
