4.8 :OUTPut Commands
:OUTPut commands are used to enable or disable channel output, OVP/OCP
function, track function, and Sense function, query the channel output mode, as well
as set and query the related information of overvoltage/overcurrent protection. The
range and default value of overvoltage/overcurrent protection corresponding to each
channel of DP2031 are shown in the table below.
Table 4.33 Range and default value of overvoltage/overcurrent protection
Channel OVP/OCP Available Range
OVP/OCP
Default Value
DP2031
Range1
CH1 (32 V/3
A)
1 mV to 35.2 V/1 mA to 3.3
A
35.2 V/3.3 A
CH2 (32 V/3
A)
1 mV to 35.2 V/1 mA to 3.3
A
35.2 V/3.3 A
CH3 (6 V/5 A) 1 mV to 6.6 V/1 mA to 5.5 A 6.6 V/5.5 A
Range2
(Optional)
CH1 (32 V/2
A)
1 mV to 35.2 V/1 mA to 2.2
A
35.2 V/2.2 A
CH2 (32 V/2
A)
1 mV to 35.2 V/1 mA to 2.2
A
35.2 V/2.2 A
CH3 (6 V/10
A)
1 mV to 6.6 V/1 mA to 11 A 6.6 V/11 A
4.8.1 :OUTPut:CVCC?
Syntax
:OUTPut:CVCC? [< source >]
Description
Queries the output mode (CV, CC, or UR) for the specified channel.
Parameter
Name
Type Range Default
<source> Discrete {CH1|CH2|CH3} -
Command System
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
45
