Remarks

• This series power supply has three output modes: constant voltage (CV),

constant current (CC), and unregulated (UR). In CV mode, the output voltage

equals to the voltage setting value, and the output current is determined by the

load; whereas in CC mode, the output current equals to the current setting value,

and the output voltage is determined by the load. UR mode is the unregulated

mode between CV and CC mode.

• If <source> is omitted, the command queries the output mode of the current

channel.

Return Format

The query returns CV, CC, or UR.

Examples

:OUTPut:CVCC? CH1 /*Queries the current output mode of CH1. The

query returns CV.*/

4.8.2 :OUTPut:MODE?

Syntax

:OUTPut:MODE? [<

source

Description

Queries the output mode (CV, CC, or UR) for the specified channel.

Parameter

Name

Type Range Default

<source> Discrete {CH1|CH2|CH3} -

Remarks

• This series power supply has three output modes:constant voltage (CV), constant

current (CC), and unregulated (UR). In CV mode, the output voltage equals to the

voltage setting value, and the output current is determined by the load; whereas

in CC mode, the output current equals to the current setting value, and the

output voltage is determined by the load. UR mode is the unregulated mode

between CV mode and CC mode.

• If <source> is omitted, the command queries the output mode of the current

channel.

Return Format

The query returns CV, CC, or UR.

Command System
