Page #69 background imageLoading...
Page #69 background image
Name Type Range Default
<current> Real
Please refer to
Table 4.33 Range and default value
of overvoltage/overcurrent protection
<lim> Discrete {MINimum|MAXimum} -
Remarks
When OCP (
[:SOURce[<n>]]:CURRent:PROTection:STATe
) is enabled, the output is
disabled automatically if the actual output current reaches the OCP level
currently set. You can send
[:SOURce[<n>]]:CURRent:PROTection:TRIPped?
to
query whether an OCP event occurred on the specified channel.
If [:SOURce[<n>]] or [<n>] is omitted, the command sets the corresponding
parameter of the channel currently selected.
You can also send
:OUTPut:OCP:VALue
to set the OCP level for the specified
channel.
Return Format
The query returns the OCP level, for example, 2.0000.
Examples
:CURR:PROT 2 /*Sets the OCP level to 2 A for the current channel.*/
:CURR:PROT? /*Queries the OCP level for the current channel. The
query returns 2.0000.*/
4.9.5 [:SOURce[<n>]]:CURRent:PROTection:STATe
Syntax
[:SOURce[<
n
>]]:CURRent:PROTection:STATe <
bool
>
[:SOURce[<
n
>]]:CURRent:PROTection:STATe?
Description
Sets or queries the on/off state of the overcurrent protection (OCP) function for the
specified channel.
Parameter
Name Type Range Default
<n> Integer {1|2|3} -
<bool> Bool {ON|OFF|1|0} 0
Command System
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
61
