Parameter
Name Type Range Default
<d> Discrete {D1|D2|D3|D4} D1
<bool> Bool {0|1|ON|OFF} 0|OFF
Remarks
After the trigger output function is enabled, the specified data line outputs high/low
level signal according to the settings in
:TRIGger:OUT:POLArity
when the specified
control source (
:TRIGger:OUT:SOURce
) is turned on.
Return Format
The query returns 0 or 1.
Examples
:TRIG:OUT D1,ON /*Enables the trigger output function of D1.*/
:TRIG:OUT? D1 /*Queries the on/off state of the D1 trigger output
function. The query returns 1.*/
Command System
124
