RIGOL Chapter 2 Command System
2-116 DSA800E Programming Guide
[:SENSe]:CORRection:CSET<n>:DATA
Syntax
[:SENSe]:CORRection:CSET<n>:DATA <freq>,<rel_ampl>{,<freq>,<rel_ampl>}
[:SENSe]:CORRection:CSET<n>:DATA?
Description
Create an amplitude correction curve using the specified data.
Query the specified amplitude correction data.
Parameter
Name
Type
Range
Default
<n>
Discrete
1|2|3|4
--
<freq>
Consecutive Real Number
0 Hz to 3.2 GHz
--
<rel_ampl>
Consecutive Real Number
-120 dB to 100 dB
--
Explanation
<n>: 1 denotes Antenna, 2 denotes Cable, 3 denotes Other and 4 denotes User.
The range of the number of points for editing is from 1 to 200.
Return Format
The query returns the specified amplitude correction data in <freq>,<rel_ampl>{,<freq>,<rel_ampl>}
format.
Example
The command below creates an amplitude correction curve.
:SENSe:CORRection:CSET1:DATA 900E6,0.3,1.0E9,0.35,1.3E9,0.2
The query below returns 900000000,0.300000,1000000000,0.350000,1300000000,0.200000.
:SENSe:CORRection:CSET1:DATA?
[:SENSe]:CORRection:CSET<n>:DATA:MERGe
Syntax
[:SENSe]:CORRection:CSET<n>:DATA:MERGe <freq>,<rel_ampl>{,<freq>,<rel_ampl>}
Description
Add correction data onto the current correction curve.
Parameter
Name
Type
Range
Default
<n>
Discrete
1|2|3|4
--
<freq>
Consecutive Real Number
0 Hz to 3.2 GHz
--
<rel_ampl>
Consecutive Real Number
-120 dB to 100 dB
--
Explanation
<n>: 1 denotes Antenna, 2 denotes Cable, 3 denotes Other and 4 denotes User.
The range of the number of points for editing is from 1 to 200.
Example
The command below adds two points onto the current correction curve.
:SENSe:CORRection:CSET1:DATA:MERGe 950E6,0.32,1.4E9,0.1
