Rigol DSA832E Programming Guide

Chapter 2 Command System RIGOL
DSA800E Programming Guide 2-31
:CALCulate:MARKer<n>:X:SPAN
Syntax
:CALCulate:MARKer<n>:X:SPAN <param>
:CALCulate:MARKer<n>:X:SPAN?
Description
Set the X value corresponding to the span of the specified Span Pair marker.
Query the X value corresponding to the span of the specified Span Pair marker.
Parameter
Name
Type
Range
Default
<n>
Discrete
1|2|3|4
--
<param> Consecutive Real Number Refer to Explanation 0
Explanation
<param> can be any value within the range currently available of the X axis.
If the current readout mode is frequency, it cannot exceed the frequency range of the sweep and the units
available are Hz (default), kHz, MHz and GHz.
If the current readout mode is time, it cannot exceed the time range of the sweep and the units available
are s (default), us, ms and ks.
Return Format
When the readout mode is frequency, the query returns the X value of the span of the marker in integer
and the unit is Hz.
When the readout mode is time or period, the query returns the X value of the span of the marker in
scientific notation and the unit is s.
Example
The command below sets the X value of the span of marker 1 (Span Pair marker) to 500 MHz (the readout
mode is frequency).
:CALCulate:MARKer1:X:SPAN 500000000
The query below returns 500000000.
:CALCulate:MARKer1:X:SPAN?
:CALCulate:MARKer<n>:X:STARt
Syntax
:CALCulate:MARKer<n>:X:STARt <param>
:CALCulate:MARKer<n>:X:STARt?
Description
Set the X value of the reference marker of the specified Delta Pair marker.
Query the X value of the reference marker of the specified Delta Pair marker.
Parameter
Name
Type
Range
Default
<n>
Discrete
1|2|3|4
--
<param> Consecutive Real Number Refer to
Explanation
--
Explanation
<param> can be any value within the range currently available of the X axis.
