:DISPlay:WINdow:TRACe:Y[:SCALe]:PDIVision
Syntax
:DISPlay:WINdow:TRACe:Y[:SCALe]:PDIVision <rel_ampl>
:DISPlay:WINdow:TRACe:Y[:SCALe]:PDIVision?
Description
Set the Y-axis scale.
Query the Y-axis scale.
Parameter
Name
Type
Range
Default
<rel_ampl>
Consecutive Real Number
0.1 dB to 20 dB
10 dB
Return Format
The query returns the Y-axis scale in scientific notation.
Example
The command below sets the Y-axis scale to 15 dB.
:DISPlay:WINdow:TRACe:Y:SCALe:PDIVision 15
The query below returns 1.500000E+01.
:DISPlay:WINdow:TRACe:Y:SCALe:PDIVision?
:DISPlay:WINdow:TRACe:Y[:SCALe]:RLEVel
Syntax
:DISPlay:WINdow:TRACe:Y[:SCALe]:RLEVel <ampl>
:DISPlay:WINdow:TRACe:Y[:SCALe]:RLEVel?
Description
Set the reference level.
Query the reference level.
Parameter
Name
Type
Range
Default
<rel_ampl>
Consecutive Real Number
-100 dBm to 20 dBm
0 dBm
Return Format
The query returns the reference level in scientific notation.
Example
The command below sets the reference level to -10 dBm.
:DISPlay:WINdow:TRACe:Y:SCALe:RLEVel -10
The query below returns -1.000000E+01.
:DISPlay:WINdow:TRACe:Y:SCALe:RLEVel?
