Rigol DSA832E Programming Guide

Chapter 2 Command System RIGOL
DSA800E Programming Guide 2-153
:SOURce:POWer:LEVel:IMMediate:AMPLitude
Syntax
:SOURce:POWer:LEVel:IMMediate:AMPLitude <ampl>
:SOURce:POWer:LEVel:IMMediate:AMPLitude?
Description
Set the output amplitude of the tracking generator in fixed power output mode.
Query the output amplitude of the tracking generator in fixed power output mode.
Parameter
Name
Type
Range
Default
<ampl>
Integer
-40 dBm to 0 dBm
-20 dBm
Return Format
The query returns the output amplitude in scientific notation.
Example
The command below sets the output amplitude to -10 dBm.
:SOURce:POWer:LEVel:IMMediate:AMPLitude -10
The query below returns -1.000000E+01.
:SOURce:POWer:LEVel:IMMediate:AMPLitude?
:SOURce:TRACe:REF:STATe
Syntax
:SOURce:TRACe:REF:STATe OFF|ON|0|1
:SOURce:TRACe:REF:STATe?
Description
Set whether to display the reference trace of normalization.
Query whether to display the reference trace of normalization.
Parameter
Name
Type
Range
Default
--
Bool
OFF|ON|0|1
OFF|0
Explanation
This command is only available when the normalization is enabled.
Return Format
The query returns 0 or 1.
Example
The command below enables the reference trace.
:SOURce:TRACe:REF:STATe ON or :SOURce:TRACe:REF:STATe 1
The query below returns 1.
:SOURce:TRACe:REF:STATe?
