RIGOL Chapter 2 Command System
2-156 DSA800E Programming Guide
Command List:
 :STATus:OPERation:CONDition?
 :STATus:OPERation:ENABle
 :STATus:OPERation[:EVENt]?
 :STATus:PRESet
 :STATus:QUEStionable:CONDition?
 :STATus:QUEStionable:ENABle
 :STATus:QUEStionable[:EVENt]?
:STATus:OPERation:CONDition?
Syntax
:STATus:OPERation:CONDition?
Description
Query the value of the condition register for the operation status register.
Return Format
The query returns the value of the condition register in integer. For example, 24.
:STATus:OPERation:ENABle
Syntax
:STATus:OPERation:ENABle <integer>
:STATus:OPERation:ENABle?
Description
Set the value of the enable register for the operation status register.
Query the value of the enable register for the operation status register.
Parameter
Name
Type
Range
Default
<integer>
Integer
Refer to Explanation
0
Explanation
The following table lists the bit definitions for the operation status register. The bit 0 to bit 2, bit 5 to bit 7,
bit 13 and bit 14 are reserved; they can be set but will not affect the instrument. The bit 15 and bit 12 to bit
8 are not used and are always treated as 0; therefore, the range of <integer> are the decimal numbers
corresponding to the binary numbers ranging from 0000000000000000 (0 in decimal) to
1111111111111111 (32767 in decimal) and of which the bit 15 and bit 12 to bit 8 are 0.
Bit
Value
Definition
0
1
Reserved
1
2
Reserved
2
4
Reserved
3
8
SWEeping
4
16
MEASuring
5
32
Reserved
6
64
Reserved
