RIGOL Chapter 2 Command System
2-8 DSA800E Programming Guide
<connected>: whether to connect the current point with the previous one. 1 denotes yes and 0 denotes no.
Note that for the first point, only 0 is available.
Up to 200 points can be edited for each limit line.
Return Format
The query returns the specified limit line information in
<x-axis>,<ampl>,<connected>{,<x-axis>,<ampl>,<connected>} format.
If no point is edited of the specified limit line, the query returns NULL.
Example
The command below creates an upper limit line with 3 points.
:CALCulate:LLINe2:DATA 50,100,0,100,150,1,200,200,1
The query below returns 50,100.000000,0,100,150.000000,1,200,200.000000,1.
:CALCulate:LLINe2:DATA?
:CALCulate:LLINe<n>:DATA:MERGe
Syntax
:CALCulate:LLINe<n>:DATA:MERGe <x-axis>,<ampl>,<connected>{,<x-axis>,<ampl>,<connected>}
Description
In the Pass/Fail test, add points onto the limit line being edited.
Parameter
Name
Type
Range
Default
<n>
Discrete
1|2
2
<x-axis>
Consecutive
Real Number
0 Hz to 3.2 GHz (X axis denotes frequency)
0 us to 3.2 ks (X axis denotes time)
--
<ampl>
Consecutive
Real Number
-400 dBm to 320 dBm --
<connected>
Discrete
0|1
0
Explanation
<n>: denote the lower limit line (1) or upper limit line (2).
<x-axis>: the frequency or time (depend on the X axis type) of the point being edited.
<ampl>: the amplitude of the point being edited.
<connected>: whether to connect the current point with the previous one. 1 denotes yes and 0 denotes no.
Note that for the first point, only 0 is available.
Up to 200 points can be edited for each limit line.
Example
The command below adds two points onto the upper limit line.
:CALCulate:LLINe2:DATA:MERG 250,200,1,300,250,1
