GX-6000 Operator’s Manual ESS-03 Calibration • 186
7 . Press and release the POWER/ENTER button. The first of the Gas Select
Screens, the standard four sensors screen, will be displayed. In addition
to the standard four sensors screen, there is a separate screen for each
installed smart sensor, and an ESCAPE screen that will take you back to
the Auto Cal menu. Use the ▲AIR and SHIFT ▼ (PANIC) buttons to
scroll through the different screens.
8 . With the ESS-03 channel’s Gas Select Screen displayed, press and
release the POWER/ENTER button.
9 . If you are calibrating anything other than an HCN sensor, continue to
Step 12.
AUTO
GAS SELECT
CH4 50 %LEL
O2 12.0 %
H2S 25.0 ppm
CO 50 ppm
AUTO
GAS SELECT
VOC 100 ppm
AUTO
GAS SELECT
ESCAPE
▲ AIR or
SHIFT ▼ (PANIC)
AUTO
GAS SELECT
HCN 10.0 ppm
▲ AIR or
SHIFT ▼ (PANIC)
▲ AIR or
SHIFT ▼ (PANIC)
▲ AIR or
SHIFT ▼ (PANIC)
To Next Page
