139
Adding Effects
In Performance mode you can use three multi-effects (MFX1, MFX2, MFX3), one chorus, and one reverb. For each of the three multi-effects, the
chorus, and the reverb, you can specify whether it will operate according to the effect settings of the performance, or according to the effect
settings of the patch or rhythm set assigned to the part you specify. The three multi-effects can be used independently, or you can connect two or
three of them in series.
In the “Signal Flow Diagram (Routing)” below, numbers 1–17 correspond to the Fantom-XR’s Effect Edit Menu screens (p. 140).
For details on parameters 1–17, refer to
“Functions of Effect Parameters”
(p. 140). For the editing procedure, refer to
“Making Effect Settings”
(p. 140).
fig.22-007
Applying Effects in Performance Mode
Signal Flow Diagram (Routing)
Patch
/Rhythm
Patch (Rhythm) Output
Chorus Output
Reverb Output
Chorus
Mastering
OUTPUT A
OUTPUT B
Reverb
1
2
3
4
5
MFX1
MFX2
MFX3
7
8
10
11
12
13
14
15
16
17
6
MAIN
REV
Part 1
Part 2
Part 3
Part 16
MFX Output
1 2
4 5
11 12
13
14
8 9 10
3
16 1715
9
7
8
10
9
7
8
10
9
6
6
6
7
Fantom-XR_r_e.book 139 ページ ２００６年４月４日 火曜日 午前１０時１４分
