143
Adding Effects
Reverb Output
fig.22-028a
Reverb Output Level
Adjusts the volume of the sound that has passed through
reverb.
Value:
0–127
Reverb Output Assign
Specifies how the sound routed through reverb will be output.
Value
A:
Output to the OUTPUT A (MIX) jacks in stereo.
B:
Output to the OUTPUT B jacks in stereo.
If the Mix/Parallel parameter is set to “MIX,” all sounds are
output from the OUTPUT A (MIX) jacks in stereo (p. 158).
Mastering Effect
Mastering effect settings apply to the entire Fantom-XR. These
settings are not for individual patches or performances.
For details on the Mastering Effect, refer to
“Mastering Effects”
(p.
146).
fig.22-029
MFX Control
To access the MFX Control screen
1.
From the Effect Edit Menu screen, turn the VALUE dial or
use [INC][DEC] to select “CTRL.”
fig.22-0063
2.
Press [ENTER].
Control 1–4 Src
(Multi-Effects Control Source 1–4)
Sets the MIDI message used to change the multi-effects parameter
with the multi-effects control.
Value
OFF:
Multi-effects control will not be used.
CC01–31, 33–95:
Controller numbers 1–31, 33–95
For more information about Control Change messages, please
refer to
“MIDI Implementation”
(p. 245).
PITCH BEND:
Pitch Bend
AFTERTOUCH:
Aftertouch
SYS CTRL1–SYS CTRL4:
MIDI messages used as common multi-
effects controls.
16
17
