Roland Fantom XR User Manual

246
MIDI Implementation
❍ Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
* Not received when Tone Receive Hold-1 parameter (PATCH/CTRL or RHYTHM/
CTRL) is OFF.
* Not received in Performance mode when Receive Hold-1 parameter (PERFORM/MIDI)
is OFF.
❍ Portamento (Controller number 65)
Status
2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* In Performance mode the Part Portamento Switch parameter (PERFORM/PART) will
change.
❍ Sostenuto (Controller number 66)
Status
2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍ Soft (Controller number 67)
Status
2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍ Legato Foot Switch (Controller number 68)
Status
2nd byte 3rd byte
BnH 44H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* In Performance mode the Part Legato Switch parameter (PERFORM/PART) will change.
❍ Hold-2 (Controller number 69)
Status
2nd byte 3rd byte
BnH 45H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* A hold movement isn’t done.
❍ Resonance (Controller number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv= Resonance value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* In Performance mode the Part Resonance Offset parameter (PERFORM/PART) will
change.
❍ Release Time (Controller number 72)
Status
2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Release Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* In Performance mode the Part Release Time Offset parameter (PERFORM/PART) will
change.
❍ Attack time (Controller number 73)
Status
2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Attack time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63),
* In Performance mode the Part Attack Time Offset parameter (PERFORM/PART) will
change.
❍ Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Cutoff value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* In Performance mode the Part Cutoff Offset parameter (PERFORM/PART) will change.
❍ Decay Time (Controller number 75)
Status
2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Decay Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* In Performance mode the Part Decay Time Offset parameter (PERFORM/PART) will
change.
❍ Vibrato Rate (Controller number 76)
Status
2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Rate value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* In Performance mode the Part Vibrato Rate parameter (PERFORM/PART) will change.
❍ Vibrato Depth (Controller number 77)
Status
2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Depth Value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* In Performance mode the Part Vibrato Depth parameter (PERFORM/PART) will change.
❍ Vibrato Delay (Controller number 78)
Status
2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Delay value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)
* In Performance mode the Part Vibrato Delay parameter (PERFORM/PART) will change.
❍ General Purpose Controller 5 (Controller number 80)
Status
2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* The Tone Level parameter (PATCH/TVA) of Tone 1 will change.
❍ General Purpose Controller 6 (Controller number 81)
Status 2nd byte 3rd byte
BnH 51H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* The Tone Level parameter (PATCH/TVA) of Tone 2 will change.
❍ General Purpose Controller 7 (Controller number 82)
Status
2nd byte 3rd byte
BnH 52H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* The Tone Level parameter (PATCH/TVA) of Tone 3 will change.
❍ General Purpose Controller 8 (Controller number 83)
Status
2nd byte 3rd byte
BnH 53H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* The Tone Level parameter (PATCH/TVA) of Tone 4 will change.
Fantom-XR_r_e.book 246 ページ ２００６年４月４日 火曜日 午前１０時１４分

Roland Fantom XR Specifications

General

Polyphony	128 voices
Multitimbral	16 parts
Wave Memory	128 MB (16-bit linear equivalent)
Display	240 x 64 dots backlit LCD
MIDI	In, Out, Thru
Storage	SmartMedia card slot
Expansion Slots	4 x SRX
Effects	Chorus: 3 types; Reverb: 5 types
Sampling	Yes
USB	Yes (MIDI)
Audio Outputs	4 (L/Mono, R, 3, 4)
Audio Inputs	2 (L/Mono, R)
