MIDI Implementation
| | 0000 dddd | Input Effect Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 12 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 16 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 22 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 26 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 32 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 36 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 42 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 46 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 17 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 18 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 19 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 52 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Input Effect Parameter 20 (12768 - 52768) |
| | | -20000 - +20000 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 56 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
❍ Performance Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Performance Name 1 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 01 | 0aaa aaaa | Performance Name 2 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 02 | 0aaa aaaa | Performance Name 3 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 03 | 0aaa aaaa | Performance Name 4 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 04 | 0aaa aaaa | Performance Name 5 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 05 | 0aaa aaaa | Performance Name 6 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 06 | 0aaa aaaa | Performance Name 7 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 07 | 0aaa aaaa | Performance Name 8 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 08 | 0aaa aaaa | Performance Name 9 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 09 | 0aaa aaaa | Performance Name 10 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0A | 0aaa aaaa | Performance Name 11 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0B | 0aaa aaaa | Performance Name 12 (32 - 127) |
| | | 32 - 127 [ASCII] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0C | 00aa aaaa | Solo Part Select (0 - 16) |
| | | OFF, 1 - 16 |
| 00 0D | 000a aaaa | MFX1 Control Channel (0 - 16) |
| | | 1 - 16, OFF |
| 00 0E | 0000 000a | (reserve) <*> (1 - 0) |
| | | |
| 00 0F | 0000 000a | (reserve) <*> (1 - 0) |
| | | |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 10 | 0aaa aaaa | Voice Reserve 1 (0 - 64) |
| | | 0 - 63, FULL |
| 00 11 | 0aaa aaaa | Voice Reserve 2 (0 - 64) |
| | | 0 - 63, FULL |
| 00 12 | 0aaa aaaa | Voice Reserve 3 (0 - 64) |
| | | 0 - 63, FULL |
| 00 13 | 0aaa aaaa | Voice Reserve 4 (0 - 64) |
| | | 0 - 63, FULL |
| 00 14 | 0aaa aaaa | Voice Reserve 5 (0 - 64) |
| | | 0 - 63, FULL |
| 00 15 | 0aaa aaaa | Voice Reserve 6 (0 - 64) |
| | | 0 - 63, FULL |
| 00 16 | 0aaa aaaa | Voice Reserve 7 (0 - 64) |
| | | 0 - 63, FULL |
| 00 17 | 0aaa aaaa | Voice Reserve 8 (0 - 64) |
| | | 0 - 63, FULL |
| 00 18 | 0aaa aaaa | Voice Reserve 9 (0 - 64) |
| | | 0 - 63, FULL |
| 00 19 | 0aaa aaaa | Voice Reserve 10 (0 - 64) |
| | | 0 - 63, FULL |
| 00 1A | 0aaa aaaa | Voice Reserve 11 (0 - 64) |
| | | 0 - 63, FULL |
| 00 1B | 0aaa aaaa | Voice Reserve 12 (0 - 64) |
| | | 0 - 63, FULL |
| 00 1C | 0aaa aaaa | Voice Reserve 13 (0 - 64) |
| | | 0 - 63, FULL |
| 00 1D | 0aaa aaaa | Voice Reserve 14 (0 - 64) |
| | | 0 - 63, FULL |
| 00 1E | 0aaa aaaa | Voice Reserve 15 (0 - 64) |
| | | 0 - 63, FULL |
| 00 1F | 0aaa aaaa | Voice Reserve 16 (0 - 64) |
| | | 0 - 63, FULL |
| 00 20 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 21 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 22 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 23 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 24 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 25 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 26 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 27 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 28 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 29 | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 2A | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 2B | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 2C | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 2D | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 2E | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
| 00 2F | 0aaa aaaa | (reserve) <*> (0 - 64) |
| | | |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 30 | 00aa aaaa | MFX1 Source (0 - 16) |
| | | PERFORM, 1 - 16 |
| 00 31 | 00aa aaaa | MFX2 Source (0 - 16) |
| | | PERFORM, 1 - 16 |
| 00 32 | 00aa aaaa | MFX3 Source (0 - 16) |
| | | PERFORM, 1 - 16 |
| 00 33 | 00aa aaaa | Chorus Source (0 - 16) |
| | | PERFORM, 1 - 16 |
| 00 34 | 00aa aaaa | Reverb Source (0 - 16) |
| | | PERFORM, 1 - 16 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 35 | 00aa aaaa | MFX2 Control Channel (0 - 16) |
| | | 1 - 16, OFF |
| 00 36 | 00aa aaaa | MFX3 Control Channel (0 - 16) |
| | | 1 - 16, OFF |
| 00 37 | 0000 aaaa | MFX Structure (0 - 15) |
| | | 1 - 16 |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 38 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
❍ Performance Common MFX
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | MFX Type (0 - 127) |
| 00 01 | 0aaa aaaa | MFX Dry Send Level (0 - 127) |
| 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) |
| 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) |
| 00 04 | 0000 00aa | MFX Output Assign (0 - 3) |
| | | A, B, ---, --- |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 05 | 0aaa aaaa | MFX Control 1 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 06 | 0aaa aaaa | MFX Control 1 Sens (1 - 127) |
| | | -63 - +63 |
| 00 07 | 0aaa aaaa | MFX Control 2 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 08 | 0aaa aaaa | MFX Control 2 Sens (1 - 127) |
| | | -63 - +63 |
| 00 09 | 0aaa aaaa | MFX Control 3 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 0A | 0aaa aaaa | MFX Control 3 Sens (1 - 127) |
| | | -63 - +63 |
| 00 0B | 0aaa aaaa | MFX Control 4 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 0C | 0aaa aaaa | MFX Control 4 Sens (1 - 127) |
| | | -63 - +63 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0D | 000a aaaa | MFX Control Assign 1 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 0E | 000a aaaa | MFX Control Assign 2 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 0F | 000a aaaa | MFX Control Assign 3 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 10 | 000a aaaa | MFX Control Assign 4 (0 - 16) |
| | | OFF, 1 - 16 |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
