Roland Fantom XR User Manual

267
MIDI Implementation
| 40 1x 13 | 0aaa aaaa | Mono / Poly Mode (0 - 1) |
| | | MODE, POLY |
| 40 1x 14 | 0aaa aaaa | Assign Mode<*> (0 - 2) |
| | | SINGLE, LIMITED-MULTI, |
| | | FULL-MULTI |
| 40 1x 15 | 0aaa aaaa | Use for Rhythm Part (0 - 2) |
| | | OFF, MAP1, MAP2 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 1x 16 | 0aaa aaaa | Pitch Key Shift (40 - 88) |
| | | -24 - +24 [semitone] |
|# 40 1x 17 | 0000 aaaa | |
| | 0000 bbbb | Pitch Offset Fine (8 - 248) |
| | | -12.0 - +12.0 [Hz] |
| 40 1x 19 | 0aaa aaaa | Part Level (CC# 7) (0 - 127) |
| 40 1x 1A | 0aaa aaaa | Velocity Sens Depth (0 - 127) |
| | | -64 - +63 |
| 40 1x 1B | 0aaa aaaa | Velocity Sens Offset (0 - 127) |
| | | -64 - +63 |
| 40 1x 1C | 0aaa aaaa | Part Panpot (CC# 10) (0 - 127) |
| | | RANDOM, L63 - 63R |
| 40 1x 1D | 0aaa aaaa | Keyboard Range Low (0 - 127) |
| 40 1x 1E | 0aaa aaaa | Keyboard Range High (0 - 127) |
| 40 1x 1F | 0aaa aaaa | CC1 Controller Number (0 - 95) |
| 40 1x 20 | 0aaa aaaa | CC2 Controller Number (0 - 95) |
| 40 1x 21 | 0aaa aaaa | Chorus Send Level (CC# 93) (0 - 127) |
| 40 1x 22 | 0aaa aaaa | Reverb Send Level (CC# 93) (0 - 127) |
| 40 1x 23 | 0000 000a | Rx. Bank Select<*> (0 - 1) |
| | | OFF, ON |
| 40 1x 24 | 0000 000a | Rx. Bank Select LSB<*> (0 - 1) |
| | | OFF, ON |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 1x 30 | 0aaa aaaa | Tone Modify 1 (Vibrato Rate) (0 - 127) |
| | | -64 - +63 |
| 40 1x 31 | 0aaa aaaa | Tone Modify 2 (Vibrato Depth) (0 - 127) |
| | | -64 - +63 |
| 40 1x 32 | 0aaa aaaa | Tone Modify 3 (TVF Cutoff Freq.) (0 - 127) |
| | | -64 - +63 |
| 40 1x 33 | 0aaa aaaa | Tone Modify 4 (TVF Resonance) (0 - 127) |
| | | -64 - +63 |
| 40 1x 34 | 0aaa aaaa | Tone Modify 5 (TVF&TVA Env. Attack) (0 - 127) |
| | | -64 - +63 |
| 40 1x 35 | 0aaa aaaa | Tone Modify 6 (TVF&TVA Env. Decay) (0 - 127) |
| | | -64 - +63 |
| 40 1x 36 | 0aaa aaaa | Tone Modify 7 (TVF&TVA ENv. Release) (0 - 127) |
| | | -64 - +63 |
| 40 1x 37 | 0aaa aaaa | Tone Modify 8 (Vibrato Delay) (0 - 127) |
| | | -64 - +63 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 1x 40 | 0aaa aaaa | Scale Tuning C (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 41 | 0aaa aaaa | Scale Tuning C# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 42 | 0aaa aaaa | Scale Tuning D (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 43 | 0aaa aaaa | Scale Tuning D# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 44 | 0aaa aaaa | Scale Tuning E (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 45 | 0aaa aaaa | Scale Tuning F (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 46 | 0aaa aaaa | Scale Tuning F# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 47 | 0aaa aaaa | Scale Tuning G (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 48 | 0aaa aaaa | Scale Tuning G# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 49 | 0aaa aaaa | Scale Tuning A (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 4A | 0aaa aaaa | Scale Tuning A# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 4B | 0aaa aaaa | Scale Tuning B (0 - 127) |
| | | -64 - +63 [cent] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 2x 00 | 0aaa aaaa | Mod Pitch Control (40 - 88) |
| | | -24 - +24 [semitone] |
| 40 2x 01 | 0aaa aaaa | Mod TVF Cutoff Control (0 - 127) |
| | | -9600 - +9600 [cent] |
| 40 2x 02 | 0aaa aaaa | Mod Amplitude Control (0 - 127) |
| | | -100.0 - +100.0 [%] |
| 40 2x 03 | 0aaa aaaa | Mod LFO1 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 04 | 0aaa aaaa | Mod LFO1 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 05 | 0aaa aaaa | Mod LFO1 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 06 | 0aaa aaaa | Mod LFO1 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
| 40 2x 07 | 0aaa aaaa | Mod LFO2 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 08 | 0aaa aaaa | Mod LFO2 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 09 | 0aaa aaaa | Mod LFO2 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 0A | 0aaa aaaa | Mod LFO2 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 2x 10 | 0aaa aaaa | Bend Pitch Control (64 - 88) |
| | | 0 - 24 [semitone] |
| 40 2x 11 | 0aaa aaaa | Bend TVF Cutoff Control (0 - 127) |
| | | -9600 - +9600 [cent] |
| 40 2x 12 | 0aaa aaaa | Bend Amplitude Control (0 - 127) |
| | | -100.0 - +100.0 [%] |
| 40 2x 13 | 0aaa aaaa | Bend LFO1 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 14 | 0aaa aaaa | Bend LFO1 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 15 | 0aaa aaaa | Bend LFO1 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 16 | 0aaa aaaa | Bend LFO1 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
| 40 2x 17 | 0aaa aaaa | Bend LFO2 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 18 | 0aaa aaaa | Bend LFO2 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 19 | 0aaa aaaa | Bend LFO2 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 1A | 0aaa aaaa | Bend LFO2 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 2x 20 | 0aaa aaaa | CAf Pitch Control (40 - 88) |
| | | -24 - +24 [semitone] |
| 40 2x 21 | 0aaa aaaa | CAf TVF Cutoff Control (0 - 127) |
| | | -9600 - +9600 [cent] |
| 40 2x 22 | 0aaa aaaa | CAf Amplitude Control (0 - 127) |
| | | -100.0 - +100.0 [%] |
| 40 2x 23 | 0aaa aaaa | CAf LFO1 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 24 | 0aaa aaaa | CAf LFO1 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 25 | 0aaa aaaa | CAf LFO1 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 26 | 0aaa aaaa | CAf LFO1 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
| 40 2x 27 | 0aaa aaaa | CAf LFO2 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 28 | 0aaa aaaa | CAf LFO2 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 29 | 0aaa aaaa | CAf LFO2 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 2A | 0aaa aaaa | CAf LFO2 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 2x 30 | 0aaa aaaa | PAf Pitch Control (40 - 88) |
| | | -24 - +24 [semitone] |
| 40 2x 31 | 0aaa aaaa | PAf TVF Cutoff Control (0 - 127) |
| | | -9600 - +9600 [cent] |
| 40 2x 32 | 0aaa aaaa | PAf Amplitude Control (0 - 127) |
| | | -100.0 - +100.0 [%] |
| 40 2x 33 | 0aaa aaaa | PAf LFO1 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 34 | 0aaa aaaa | PAf LFO1 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 35 | 0aaa aaaa | PAf LFO1 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 36 | 0aaa aaaa | PAf LFO1 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
| 40 2x 37 | 0aaa aaaa | PAf LFO2 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 38 | 0aaa aaaa | PAf LFO2 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 39 | 0aaa aaaa | PAf LFO2 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 3A | 0aaa aaaa | PAf LFO2 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 2x 40 | 0aaa aaaa | CC1 Pitch Control (40 - 88) |
| | | -24 - +24 [semitone] |
| 40 2x 41 | 0aaa aaaa | CC1 TVF Cutoff Control (0 - 127) |
| | | -9600 - +9600 [cent] |
| 40 2x 42 | 0aaa aaaa | CC1 Amplitude Control (0 - 127) |
| | | -100.0 - +100.0 [%] |
| 40 2x 43 | 0aaa aaaa | CC1 LFO1 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 44 | 0aaa aaaa | CC1 LFO1 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 45 | 0aaa aaaa | CC1 LFO1 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 46 | 0aaa aaaa | CC1 LFO1 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
| 40 2x 47 | 0aaa aaaa | CC1 LFO2 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 48 | 0aaa aaaa | CC1 LFO2 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 49 | 0aaa aaaa | CC1 LFO2 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 4A | 0aaa aaaa | CC1 LFO2 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 40 2x 50 | 0aaa aaaa | CC2 Pitch Control (40 - 88) |
| | | -24 - +24 [semitone] |
| 40 2x 51 | 0aaa aaaa | CC2 TVF Cutoff Control (0 - 127) |
| | | -9600 - +9600 [cent] |
| 40 2x 52 | 0aaa aaaa | CC2 Amplitude Control (0 - 127) |
| | | -100.0 - +100.0 [%] |
| 40 2x 53 | 0aaa aaaa | CC2 LFO1 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 54 | 0aaa aaaa | CC2 LFO1 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 55 | 0aaa aaaa | CC2 LFO1 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 56 | 0aaa aaaa | CC2 LFO1 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
| 40 2x 57 | 0aaa aaaa | CC2 LFO2 Rate Control (0 - 127) |
| | | -10.0 - +10.0 [Hz] |
| 40 2x 58 | 0aaa aaaa | CC2 LFO2 Pitch Control (0 - 127) |
| | | 0 - 600 [cent] |
| 40 2x 59 | 0aaa aaaa | CC2 LFO2 TVF Depth (0 - 127) |
| | | 0 - 2400 [cent] |
| 40 2x 5A | 0aaa aaaa | CC2 LFO2 TVA Depth (0 - 127) |
| | | 0 - 100.0 [%] |
+——————————————————————————————————————————————————————————————————————————————+
x: BLOCK NUMBER (0-F)
Part 1 (MIDI ch = 1) x = 1
Part 2 (MIDI ch = 2) x = 2
: : :
Part 9 (MIDI ch = 9) x = 9
Part10 (MIDI ch = 10) x = 0
Part11 (MIDI ch = 11) x = A
Part12 (MIDI ch = 12) x = B
: : :
Part16 (MIDI ch = 16) x = F
❍ Drum Setup Parameter
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 41 m0 00 | 0aaa aaaa | Drum Map Name 1 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 01 | 0aaa aaaa | Drum Map Name 2 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 02 | 0aaa aaaa | Drum Map Name 3 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 03 | 0aaa aaaa | Drum Map Name 4 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 04 | 0aaa aaaa | Drum Map Name 5 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 05 | 0aaa aaaa | Drum Map Name 6 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 06 | 0aaa aaaa | Drum Map Name 7 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 07 | 0aaa aaaa | Drum Map Name 8 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 08 | 0aaa aaaa | Drum Map Name 9 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 09 | 0aaa aaaa | Drum Map Name 10 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 0A | 0aaa aaaa | Drum Map Name 11 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 41 m0 0B | 0aaa aaaa | Drum Map Name 12 (32 - 127) |
| | | 32 - 127 [ASCII] |
|—————————————+———————————+————————————————————————————————————————————————————|
| 41 m1 rr | 0aaa aaaa | Play Note Number (0 - 127) |
| 41 m2 rr | 0aaa aaaa | Level (0 - 127) |
| 41 m3 rr | 0aaa aaaa | Assign Group Number (0 - 127) |
| | | NON, 1 - 127 |
| 41 m4 rr | 0aaa aaaa | Panpot (0 - 127) |
| | | RAMDOM, L63 - 63R |
| 41 m5 rr | 0aaa aaaa | Reverb Send Level (0 - 127) |
| | | 0.0 - 1.0 |
| 41 m6 rr | 0aaa aaaa | Chorus Send Level (0 - 127) |
| | | 0.0 - 1.0 |
| 41 m7 rr | 0000 000a | Rx. Note Off (0 - 1) |
| | | OFF, ON |
| 41 m8 rr | 0000 000a | Rx. Note On (0 - 1) |
| | | OFF, ON |
|—————————————+————————————————————————————————————————————————————————————————|
m: Map number (0 = MAP1, 1 = MAP2)
rr: drum part note number (00H-7FH)
