TM Status Field
The TM Status field displays whether a Trunk Master is connected to the system.
Available statuses are
:
Link 1 and Link 2 Columns
The Link 1 and Link 2 columns display the status information for the active and standby trunk master. A Trunk Master can consist
of an active and standby pair. The intercom maintains links to both – Link 1 and Link 2.
Connected Field
The Connected field displays the connection status of the Ethernet link.
Active Field
The Active field displays whether the Trunk Master on this link is active.
IP Address Field
The IP Address field displays the IP address of the Trunk Master.
Link Ups Field
The Link Ups field displays how many times a connection was established. Normally this value is very low (for example, 1 or 2);
however if there are network problems, a higher number may display.
The TM is connected.
The TM was connected, but is no longer connected.
There is pending data being sent to the TM.
There is no TM configured.
The TM is connected.
The TM was connected, but is no longer connected.
There is no connection.
The TM is active.
There TM is not active.
