82 Menu System Description ODIN Intercom Matrix
Status Menu
The Status menu is used to view status information related to the following areas:
System
Network
Ports
Peripherals
Intercom
Hardware
System Menu
The System menu contains information about the firmware used in ODIN, AZedit, and IPedit sessions currently running.
ODIN Versions
The ODIN Versions screen displays the current versions for each firmware component in the system.
NOTE: If RVON is not supported on the ODIN, then LEC (Line Echo Cancellation) Application displays.
FIGURE 11. Status Menu Icons
FIGURE 12. Status | System Menu Items
FIGURE 13. Status | System | ODIN Versions
