ODIN Intercom Matrix Basic Operation 37
Misc.
The Misc. section contains additional status information for Alarms, AZedit sessions, IPedit sessions, PTP clock stats, and TM
status.
For Alarms X/Y is shown, where X is the number of unacknowledged alarms and where Y is the total number of active alarms.
• when shown in red, X is greater than 0
• when shown in yellow, X is equal to 0 and Y is greater than 0
• when shown in green, X and Y are equal to 0
For AZedit The number of active AZedit sessions.
• when shown in green, there is at least one AZedit connection
• when shown in yellow, there are no AZedit connections
For IPedit The number of active IPedit sessions.
• when shown in green, there is at least one IPedit connection
• when shown in yellow, there are no IPedit connections
For CLK The status of the PTP clock.
• when a green LED is displayed, the PTP clock is linked
• when a red LED is displayed, the PTP clock is not linked
For TM The status of the TM (Trunk Master)
• when a green LED is displayed, an active link to the TM is detected
• when a red LED is displayed, no active link to the TM is detected, but the TM is defined
• when a grey LED is displayed, no TM is defined
