CHAPTER 3
Installation and Maintenance
Introduction
The ODIN Digital Intercom is a highly scalable intercom system in a 1RU (Rack Unit) package. Up to eight ODIN frames can be
interconnected via optical Inter-Frame Links creating a single matrix with up to 1024 ports.
IMPORTANT: ODIN acts as a common connection point for the ground connections associated with each power supply (2
total). If a ground difference exists between the two power supply inputs to ODIN, audio noise or
performance degradation may result. If possible, avoid powering ODIN with sources having different
ground potentials.
CAUTION:
• If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack
environment may be greater than the room ambient temperature. Therefore, special consideration should be
given to installing the equipment in an environment compatible with the specified maximum ambient
operating temperature.
• Minimum 4” clearance on left and right sides of ODIN is required to keep the fan area unobstructed and
ensure proper ventilation.
• ODIN is to be connected to mains socket outlet with a protective earth connection. Particular attention
should be given to power supply connections other than direct connection to the mains socket. This includes
using power strips with earth grounding.
• Consideration should be taken to ensure the mains power supply current and voltage meet the ratings
specified on the equipment name plate.
Requirements
AZedit....................................................................................................................................v5.4.0 or later
IPedit.....................................................................................................................................v3.6.0 or later
KP Series...............................................................................................................................v2.1.4 or later
KP Series-RVON ...................................................................................................................v1.5.0 or later
RVON-KP / RVON-IO / RVON-16 / RVON-C.......................................................................v2.7.0 or later
OMI.......................................................................................................................................v6.2.0 or later
OKI........................................................................................................................................v6.1.2 or later
OEI-2 .....................................................................................................................................v2.10 or later
ROAMEO ..............................................................................................................................v8.1.1 or later
TrunkEdit ..............................................................................................................................v1.8.1 or later
Trunk Supervisor...................................................................................................................v1.9.2 or later
NOTE: For downloading instructions, see “Firmware” on page 73.
