ODIN Intercom Matrix Menu System Description 97
Status Field
The Status field displays the status of the TIF.
Available states are:
Off-hook
Ringing
– (on-hook/idle)
Peripherals Menu
The Peripherals menu contains a list of the different types of peripheral devices available.
Device statuses include:
Trunk Master
GPIO-16
LCP-102
PAP-32
PAP-5032
Trunk Master
The Trunk Master screen displays the status information of the Trunk Master(s) connected to the selected frame.
FIGURE 29. Status | Peripherals Menu Icons
FIGURE 30. Status | Peripherals | Trunk Master
