16 Introduction ODIN Intercom Matrix
Licensing
ODIN comes in 16-port, 32-port, 64-port, and 128-port versions, with an option to upgrade in 16-port increments on all
versions (except the 128-port version).
For more information, see “Download a Splash Screen, Screen Saver or Licenses” on page 77.
ODIN System Descriptions
Single-Frame System
ODIN can connect to keypanels via OMNEO, RVON, and AIO. Up to 16 analog panels can be directly connected via the AIO
ports on the back of each ODIN frame..
FIGURE 3. Single-Frame System
