RTS ODIN - Page 19

ODIN Intercom Matrix Introduction 15
GPIO Connector: J5
Pin Assignment Silk Screen
1
RELAY1_COM C
2 RELAY1_NC NC
3 RELAY1_NO NO
4 RELAY2_COM C
5 RELAY2_NC NC
6 RELAY2_NO NO
7 OPTO1_ANODE A+
8 OPTO1_CATHODE K-
9
Chassis GND
10 OPTO2_ANODE A+
11 OPTO2_CATHODE K-
12
Chassis GND
13
RELAY3_COM C
14 RELAY3_NC NC
15 RELAY3_NO NO
16 RELAY4_COM C
17 RELAY4_NC NC
18 RELAY4_NO NO
19 OPTO3_ANODE A+
20 OPTO3_CATHODE K-
21
Chassis GND
22 OPTO4_ANODE A+
23 OPTO4_CATHODE K-
24
Chassis GND
a
PAP/LCP/GPIO16: J6
a. Only used for PAP-32 devices, not PAP-5032 devices.
Pin Assignment
1 RS-485 +
2
RS-485 -
3N/C
4N/C
5N/C
6N/C
7 RS-485 +
8 RS-485 -
CONTROL & RVON: J8
Ethernet x 2
Pin Assignment
1 Data 1 +
2 Data 1 -
3 Data 2 +
4 Data 3 +
5 Data 3 -
6 Data 2-
7 Data 4+
8 Data 4-
OMNEO ETHERNET: J10
RJ-45 x 2
Supports 10/100/1000 Ethernet
Pin Assignment
1 Data 1 +
2 Data 1 -
3 Data 2 +
4 Data 3 +
5 Data 3 -
6 Data 2-
7 Data 4+
8 Data 4-
