106 Menu System Description ODIN Intercom Matrix
Active Field
The Active field displays whether or not the fiber link is active.
IP Address Field
The IP Address field displays the IP address of the selected frame.
Faults Field
The Faults field displays a red x if two frames are connected to form a multi-frame intercom, but the configurations do not match.
When two frame configurations do not match, the intercom prevents the frames from communicating with each other. If the frames
continue to operate autonomously even though the link between them is up, the fault icon is displayed.
Link Ups Field
The Link Ups field displays how many times a connection was established.
Round Trip Field
The Round Trip field displays approximately how long, in milliseconds, it takes for a message from the intercom to be
acknowledged.
NOTE: Round Trip is an average value. It should never be any higher than a predetermined maximum (currently 5 seconds).
If this value goes higher, the link may fail.
The range for this field is 0 – 5.
Packets To Field
The Packets To field displays the number of packets (for example, messages) sent to the frame from this frame.
The frame is connected.
There is no connection.
There are no errors.
An error has occurred. While the field is highlighted, press the SEL button to display a fault description.
Faults include:
a
a. An <N> or similar symbol with the message text denotes a numeric value inserted by the software at runtime.
Frame ID Mismatch: The other frame
thinks this is Frame <N>
Indicates this frame and the other frame disagree as to the number of
this frame, with <N> being the number that the other frame expects.
Frame ID Mismatch: The other frame is
<N1> not <N2>
Indicates with <N1> what this frame expects the other frame to be
numbered, and <N2> what the other frame is reporting at its number.
Frame ID Mismatch: The other frame is
also frame <N>
Indicates both this frame and the other frame have the same number
<n>.
The other frame has a different
configuration than this frame
Indicates the intercom configuration between frames is not identical.
Link is inactive (unknown cause) Indicates the link is inactive with no known cause.
No State Information Received Indicates no status information is available.
